uCOM-ASL
SMARC Module with Intel Atom® Processor x7000RE Series
- LPDDR5(x) x 1, up to 16GB
- eMMC, up to 64GB
- DP++ x 2, eDP x 1
- USB 3.2 Gen 2 x 2, USB 2.0 x 6
- PCIe Gen 3 [x1] x 3, max 1x PCIe[x2]
- Intel® Ethernet Controller I226-V/IT x 2
- 5V input
- SMARC Module size 82mm x 50mm
| PART NUMBER | UCOM-ASLW2-B10-0001 | UCOM-ASLW2-B10-0002 |
|---|---|---|
| Form Factor | SMARC | SMARC |
| CPU | Intel Atom® x7835RE Processor | Intel Atom® x7433RE Processor |
| Memory | 16GB LPDDR5 | 8GB LPDDR5x |
| ECC support | — | — |
| Display | eDP x 1 DP++ x 2 | eDP x 1 DP++ x 2 |
| Storage | 64GB eMMC | 64GB eMMC |
| LAN | Intel® Ethernet Controller I226-IT x 2 | Intel® Ethernet Controller I226-IT x 2 |
| USB | USB 3.2 x 2 USB 2.0 x 6 | USB 3.2 x 2 USB 2.0 x 6 |
| UART | 4-wire UART x 2, 2-Wire UART x 2 | 4-wire UART x 2, 2-Wire UART x 2 |
| Expansion | PCIe [x1] x 3 | PCIe [x1] x 3 |
| Power | +5V | +5V |
| Temperature | -40°C ~ 85°C | -40°C ~ 85°C |
| Others | LPC, GPIO 7-bit, I2C, SMBus | LPC, GPIO 7-bit, I2C, SMBus |
If you are interested in our product, you can contact us through our contact page.
In order to use the wishlist please make sure you are registered as a user to proceed.
OK
SKU:
uCOM-ASL
Product information "uCOM-ASL"
SMARC Module with Intel Atom® Processor x7000RE Series
- LPDDR5(x) x 1, up to 16GB
- eMMC, up to 64GB
- DP++ x 2, eDP x 1
- USB 3.2 Gen 2 x 2, USB 2.0 x 6
- PCIe Gen 3 [x1] x 3, max 1x PCIe[x2]
- Intel® Ethernet Controller I226-V/IT x 2
- 5V input
- SMARC Module size 82mm x 50mm
| PART NUMBER | UCOM-ASLW2-B10-0001 | UCOM-ASLW2-B10-0002 |
|---|---|---|
| Form Factor | SMARC | SMARC |
| CPU | Intel Atom® x7835RE Processor | Intel Atom® x7433RE Processor |
| Memory | 16GB LPDDR5 | 8GB LPDDR5x |
| ECC support | — | — |
| Display | eDP x 1 DP++ x 2 | eDP x 1 DP++ x 2 |
| Storage | 64GB eMMC | 64GB eMMC |
| LAN | Intel® Ethernet Controller I226-IT x 2 | Intel® Ethernet Controller I226-IT x 2 |
| USB | USB 3.2 x 2 USB 2.0 x 6 | USB 3.2 x 2 USB 2.0 x 6 |
| UART | 4-wire UART x 2, 2-Wire UART x 2 | 4-wire UART x 2, 2-Wire UART x 2 |
| Expansion | PCIe [x1] x 3 | PCIe [x1] x 3 |
| Power | +5V | +5V |
| Temperature | -40°C ~ 85°C | -40°C ~ 85°C |
| Others | LPC, GPIO 7-bit, I2C, SMBus | LPC, GPIO 7-bit, I2C, SMBus |
| Operating humidity Technical Data: | 0% - 90% relative humidity |
|---|---|
| Power Supply Type Technical Data: | AT/ATX |
| SMBus/I2C Technical Data: | I2C/SMbus x 1 |
| CPU: | Intel® Atom™ x7211RE/ x7213RE/ x7433RE/ x7835RE |
| Processor Family: | Intel® Atom™ x7000E Series |
| Memory : | Up to 16GB LPDDR5 |
| Display : | Display Port ++ |
| Ethernet Ports: | 1-2, 3-4 |
| Interface: | eDP |
| Storage : | eMMC, up to 64GB |
| USB Ports: | USB 2.0 x 6 (pin header), USB 3.2 x 2 (pin header) |
| USBs: | 5-8 |
| COM: | UART x 2 (4-wire), UART x 2 (2-wire) |
| Expansion : | PCIe Gen 3 [x1] x 3, SATA 6Gb/s x1 |
| Operating System : | Linux, Windows 10, Windows 11 |
| TPM : | TPM 2.0 |
| Ethernet Technical Data: | I226-V/IT 2.5GbE x 2 |
| Certifications: | CE, FCC class A |
| Dimensions Technical Data: | 82mm x 50mm |
| DIO/GPIO Technical Data: | 7 bit GPIO |
| Audio Technical Data: | High Definition Audio Interface |
