de next-RAP8
86mm x 55mm Single Board with 13th Generation Intel® Core™ i7/i5/i3 Processor
Key Features
- Onboard 13th Gen. Intel® Core™ Series Processor, TDP 15W
- Onboard LPDDR5x up to 16GB
- HDMI 1.4b x 1, eDP x 1
- Â 2.5GbE RJ45 x 1, GbE RJ45 x 1
- Â USB 3.2 Gen 2 x 2, USB 2.0 x 4
- Â M.2 2280 M-Key x 1 (PCIe [x2]), PCIe Gen 3 [x4] via FPC x 1Â
- DC 12Vin
| PART NUMBER | DENEXT-RAP8-A10-0001 | DENEXT-RAP8-A10-0002 | DENEXT-RAP8-A10-0003 |
|---|---|---|---|
| CPU | Intel® Core™ i7- 1365UE | Intel® Core™ i5- 1335UE | Intel® Core™ i3- 1315UE |
| Memory | Onboard LPDDR5x 16GB | Onboard LPDDR5x 16GB | Onboard LPDDR5x 16GB |
| Display | eDP x 1 , HDMI x 1 | eDP x 1 , HDMI x 1 | eDP x 1 , HDMI x 1 |
| Storage | SATA 6.0 Gbps x 1 | SATA 6.0 Gbps x 1 | SATA 6.0 Gbps x 1 |
| LAN | 2.5GbE x 1, GbE x 1 | 2.5GbE x 1, GbE x 1 | 2.5GbE x 1, GbE x 1 |
| USB | USB 3.2 Gen 2 x 2 , USB 2.0 x 4 | USB 3.2 Gen 2 x 2 , USB 2.0 x 4 | USB 3.2 Gen 2 x 2 , USB 2.0 x 4 |
| COM Port | RS232/422/485 x 2 | RS232/422/485 x 2 | RS232/422/485 x 2 |
| Expansion | M.2 2280 M-key x 1 , FPC Connector x 1 | M.2 2280 M-key x 1 , FPC Connector x 1 | M.2 2280 M-key x 1 , FPC Connector x 1 |
| TPM | fTPM | fTPM | fTPM |
| Power | +12V in (DC Jack) | +12V in (DC Jack) | +12V in (DC Jack) |
| Operating Temperature | 0°C ~ 60°C | 0°C ~ 60°C | 0°C ~ 60°C |
| Others | GPIO 8 bits | GPIO 8 bits | GPIO 8 bits |
If you are interested in our product, you can contact us through our contact page.
In order to use the wishlist please make sure you are registered as a user to proceed.
OK
SKU:
de next-RAP8
Product information "de next-RAP8"
86mm x 55mm Single Board with 13th Generation Intel® Core™ i7/i5/i3 Processor
Key Features
- Onboard 13th Gen. Intel® Core™ Series Processor, TDP 15W
- Onboard LPDDR5x up to 16GB
- HDMI 1.4b x 1, eDP x 1
- Â 2.5GbE RJ45 x 1, GbE RJ45 x 1
- Â USB 3.2 Gen 2 x 2, USB 2.0 x 4
- Â M.2 2280 M-Key x 1 (PCIe [x2]), PCIe Gen 3 [x4] via FPC x 1Â
- DC 12Vin
| PART NUMBER | DENEXT-RAP8-A10-0001 | DENEXT-RAP8-A10-0002 | DENEXT-RAP8-A10-0003 |
|---|---|---|---|
| CPU | Intel® Core™ i7- 1365UE | Intel® Core™ i5- 1335UE | Intel® Core™ i3- 1315UE |
| Memory | Onboard LPDDR5x 16GB | Onboard LPDDR5x 16GB | Onboard LPDDR5x 16GB |
| Display | eDP x 1 , HDMI x 1 | eDP x 1 , HDMI x 1 | eDP x 1 , HDMI x 1 |
| Storage | SATA 6.0 Gbps x 1 | SATA 6.0 Gbps x 1 | SATA 6.0 Gbps x 1 |
| LAN | 2.5GbE x 1, GbE x 1 | 2.5GbE x 1, GbE x 1 | 2.5GbE x 1, GbE x 1 |
| USB | USB 3.2 Gen 2 x 2 , USB 2.0 x 4 | USB 3.2 Gen 2 x 2 , USB 2.0 x 4 | USB 3.2 Gen 2 x 2 , USB 2.0 x 4 |
| COM Port | RS232/422/485 x 2 | RS232/422/485 x 2 | RS232/422/485 x 2 |
| Expansion | M.2 2280 M-key x 1 , FPC Connector x 1 | M.2 2280 M-key x 1 , FPC Connector x 1 | M.2 2280 M-key x 1 , FPC Connector x 1 |
| TPM | fTPM | fTPM | fTPM |
| Power | +12V in (DC Jack) | +12V in (DC Jack) | +12V in (DC Jack) |
| Operating Temperature | 0°C ~ 60°C | 0°C ~ 60°C | 0°C ~ 60°C |
| Others | GPIO 8 bits | GPIO 8 bits | GPIO 8 bits |
| CPU: | 12th gen Intel® Core™ i7/i5/i3 or Celeron® processor, i3-1315UE, i5-1335UE, i7-1365UE |
|---|---|
| Processor Family: | Intel® Core |
| Memory : | 16G |
| Display : | HDMI / eDP |
| Storage : | SATA 6.0 Gb/s x 1 |
| USB Ports: | USB2.0 x 4 (header), USB3.2 GEN2 x 2 (Rear) |
| Expansion : | M.2 2280 M-key x 1, mPCle |
| Power Requirement: | 12v |
| Operating Temperature : | 0 to +60 degC |
| Ethernet Technical Data: | I226-V/IT 2.5GbE x 2, i219, 1GbE RJ-45 x 1 |
