Plus-Line 54.6 IoT
PLUS-Line 54.6 IoT – UHD Open Frame Monitor with Integrated Raspberry® Controller
The PLUS-Line 54.6 IoT is a high-performance open frame monitor designed for industrial environments. Featuring a 54.6" Ultra HD resolution display, it delivers exceptional image clarity and enables the simultaneous viewing of multiple data streams — including the ability to display four Full HD images without scaling.
Built for Industry 4.0 applications, this model comes equipped with an integrated Raspberry® IoT controller, offering a reliable platform for connected, data-driven systems.
The monitor is available in multiple configurations:
-
TrueFlat glass
-
TrueFlat glass with 20-point PCAP touchscreen
When correctly sealed between the front panel and enclosure by the user, both versions offer IP65-rated protection at the front — ideal for demanding environments requiring resistance to dust and water ingress.
Available Configurations:
-
MO-41-081 | PLUS-Line 54.6 IoT – Open frame, basic version
-
MO-41-235 | PLUS-Line 54.6 IoT – With front bezel
-
MO-41-082 | PLUS-Line 54.6 IoT – With TrueFlat glass
-
MO-41-083 | PLUS-Line 54.6 IoT – With TrueFlat glass and PCAP touchscreen
If you are interested in our product, you can contact us through our contact page.
PLUS-Line 54.6 IoT – UHD Open Frame Monitor with Integrated Raspberry® Controller
The PLUS-Line 54.6 IoT is a high-performance open frame monitor designed for industrial environments. Featuring a 54.6" Ultra HD resolution display, it delivers exceptional image clarity and enables the simultaneous viewing of multiple data streams — including the ability to display four Full HD images without scaling.
Built for Industry 4.0 applications, this model comes equipped with an integrated Raspberry® IoT controller, offering a reliable platform for connected, data-driven systems.
The monitor is available in multiple configurations:
-
TrueFlat glass
-
TrueFlat glass with 20-point PCAP touchscreen
When correctly sealed between the front panel and enclosure by the user, both versions offer IP65-rated protection at the front — ideal for demanding environments requiring resistance to dust and water ingress.
Available Configurations:
-
MO-41-081 | PLUS-Line 54.6 IoT – Open frame, basic version
-
MO-41-235 | PLUS-Line 54.6 IoT – With front bezel
-
MO-41-082 | PLUS-Line 54.6 IoT – With TrueFlat glass
-
MO-41-083 | PLUS-Line 54.6 IoT – With TrueFlat glass and PCAP touchscreen
| Screen Diagonal: | 54.6" |
|---|---|
| Viewing Angle: | 89°/89°/89°/89° |
| Brightness: | 700cd/m2 |
| Ratio: | 4000:1 |
