GENE-ASL6
3.5” SubCompact Board with Intel Atom® Processors x7000RE Series Processors
- Intel Atom® Processors x7000RE Series Processors
- DDR5 4800 MHz, SODIMM x 1, Up to 16GB
- HDMI 1.4, VGA, LVDS x 1
- Intel 2.5GbE x 3, SATA 6.0 Gb/s x 1, GPIO x 8bit
- USB3.2 Gen2 x 2, USB2.0 x 4, RS-232/422/485 x 2, RS-232 x 2
- Mini PCIe card x 1, M.2 E-Key 2230 x 1, M.2 B-Key 3052 x 1
| PART NUMBER | GENE-ASL6W2-A10-0001 | GENE-ASL6W2-A10-0002 | GENE-ASL6W2-A10-0003 |
|---|---|---|---|
| CPU | x7433RE | x7213RE | x7835RE |
| DISPLAY | HDMI x1 VGA x1 LVDS x1 | HDMI x1 VGA x1 LVDS x1 | HDMI x1 VGA x1 LVDS x1 |
| LAN | 2.5GbE x 3 | 2.5GbE x 3 | 2.5GbE x 3 |
| USB | USB 3.2 Gen 2 x 2 USB 2.0 x 4 | USB 3.2 Gen 2 x 2 USB 2.0 x 4 | USB 3.2 Gen 2 x 2 USB 2.0 x 4 |
| RS-232 | 2 | 2 | 2 |
| RS- 232/422/485 | 2 | 2 | 2 |
| STORAGE | SATA x 1 | SATA x 1 | SATA x 1 |
| EXPANSION SLOT | M.2 3052 B-Key x 1 M.2 2230 E-Key x 1 MiniCard x 1 | M.2 3052 B-Key x 1 M.2 2230 E-Key x 1 MiniCard x 1 | M.2 3052 B-Key x 1 M.2 2230 E-Key x 1 MiniCard x 1 |
| TPM | 2.0 | 2.0 | 2.0 |
| POWER | 12V | 12V | 12V |
| TEMP | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| OTHERS | Nano SIM, GPIO x 8, SMBUS | Nano SIM, GPIO x 8, SMBUS | Nano SIM, GPIO x 8, SMBUS |
If you are interested in our product, you can contact us through our contact page.
In order to use the wishlist please make sure you are registered as a user to proceed.
OK
SKU:
GENE-ASL6
Product information "GENE-ASL6"
3.5” SubCompact Board with Intel Atom® Processors x7000RE Series Processors
- Intel Atom® Processors x7000RE Series Processors
- DDR5 4800 MHz, SODIMM x 1, Up to 16GB
- HDMI 1.4, VGA, LVDS x 1
- Intel 2.5GbE x 3, SATA 6.0 Gb/s x 1, GPIO x 8bit
- USB3.2 Gen2 x 2, USB2.0 x 4, RS-232/422/485 x 2, RS-232 x 2
- Mini PCIe card x 1, M.2 E-Key 2230 x 1, M.2 B-Key 3052 x 1
| PART NUMBER | GENE-ASL6W2-A10-0001 | GENE-ASL6W2-A10-0002 | GENE-ASL6W2-A10-0003 |
|---|---|---|---|
| CPU | x7433RE | x7213RE | x7835RE |
| DISPLAY | HDMI x1 VGA x1 LVDS x1 | HDMI x1 VGA x1 LVDS x1 | HDMI x1 VGA x1 LVDS x1 |
| LAN | 2.5GbE x 3 | 2.5GbE x 3 | 2.5GbE x 3 |
| USB | USB 3.2 Gen 2 x 2 USB 2.0 x 4 | USB 3.2 Gen 2 x 2 USB 2.0 x 4 | USB 3.2 Gen 2 x 2 USB 2.0 x 4 |
| RS-232 | 2 | 2 | 2 |
| RS- 232/422/485 | 2 | 2 | 2 |
| STORAGE | SATA x 1 | SATA x 1 | SATA x 1 |
| EXPANSION SLOT | M.2 3052 B-Key x 1 M.2 2230 E-Key x 1 MiniCard x 1 | M.2 3052 B-Key x 1 M.2 2230 E-Key x 1 MiniCard x 1 | M.2 3052 B-Key x 1 M.2 2230 E-Key x 1 MiniCard x 1 |
| TPM | 2.0 | 2.0 | 2.0 |
| POWER | 12V | 12V | 12V |
| TEMP | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| OTHERS | Nano SIM, GPIO x 8, SMBUS | Nano SIM, GPIO x 8, SMBUS | Nano SIM, GPIO x 8, SMBUS |
| CPU: | x7213RE, x7433RE, x7835RE |
|---|---|
| Processor Family: | Intel® Atom® |
| Memory : | 16GB |
| Display : | HDMI, LVDS, VGA |
| Storage : | SATA III x1 |
| USB Ports: | USB 3.2 Gen 2 x2, USB 2.0 (Pin headers) x4 |
| Expansion : | M.2 2230 E-Key x 1, M.2 3052 B-key x 1 |
| Power Requirement: | 9 to 36V (Optional 12V) |
| Operating Temperature : | -40 to +85 degC |
| Ethernet Technical Data: | 2.5GbE RJ-45 x 3, i226 |
