CEM320
Key features:
- Intel Atom® x6000E/RE series or Intel® Celeron® N/J processor (Elkhart Lake)
- 8GB/16GB LPDDR4 onboard memory, up to 3200 MT/s
- Up to 4 PCIe Gen 3 lanes
- 2 SATA 3.0
- 2 USB 3.2 Gen 2 and 8 USB 2.0
- eMMC 5.1 and TPM 2.0 onboard
| Model | CEM320-X6413-16GB | CEM320-N6210-8GB | CEM320-J6412-8GB | CEM320-X6414- 16GB |
| CPU | COM Express Type 10 Mini module with Intel Atom® X6413E | COM Express Type 10 Mini module with Intel® Celeron® N6210 | COM Express Type 10 Mini module with Intel® Celeron® J6412 | COM Express Type 10 Mini module with Intel Atom® x6414RE |
| Display | DDI, LVDS | DDI, LVDS | DDI, LVDS | DDI, LVDS |
| Storage | 64GB eMMC | 32GB eMMC | 64GB eMMC | 64GB eMMC |
| Memory | 16GB LPDDR4 | 8GB LPDDR4 | 8GB LPDDR4 | 16GB LPDDR4 |
| LAN | GbE LAN | GbE LAN | GbE LAN | GbE LAN |
| USB | USB 3.0 | USB 3.0 | USB 3.0 | USB 3.0 |
If you are interested in our product, you can contact us through our contact page.
In order to use the wishlist please make sure you are registered as a user to proceed.
OK
SKU:
CEM320
Product information "CEM320"
Key features:
- Intel Atom® x6000E/RE series or Intel® Celeron® N/J processor (Elkhart Lake)
- 8GB/16GB LPDDR4 onboard memory, up to 3200 MT/s
- Up to 4 PCIe Gen 3 lanes
- 2 SATA 3.0
- 2 USB 3.2 Gen 2 and 8 USB 2.0
- eMMC 5.1 and TPM 2.0 onboard
| Model | CEM320-X6413-16GB | CEM320-N6210-8GB | CEM320-J6412-8GB | CEM320-X6414- 16GB |
| CPU | COM Express Type 10 Mini module with Intel Atom® X6413E | COM Express Type 10 Mini module with Intel® Celeron® N6210 | COM Express Type 10 Mini module with Intel® Celeron® J6412 | COM Express Type 10 Mini module with Intel Atom® x6414RE |
| Display | DDI, LVDS | DDI, LVDS | DDI, LVDS | DDI, LVDS |
| Storage | 64GB eMMC | 32GB eMMC | 64GB eMMC | 64GB eMMC |
| Memory | 16GB LPDDR4 | 8GB LPDDR4 | 8GB LPDDR4 | 16GB LPDDR4 |
| LAN | GbE LAN | GbE LAN | GbE LAN | GbE LAN |
| USB | USB 3.0 | USB 3.0 | USB 3.0 | USB 3.0 |
| CPU: | Intel Atom® x6425RE/x6413E/x6414RE, J6412, N6210 |
|---|---|
| Processor Family: | Intel Atom® x6000E Series, Intel® Celeron® (Elkhart Lake) |
| Memory : | 8GB/16GB LPDDR4 memory onboard, up to 3200 MT/s |
| Display : | DDI, LVDS |
| Storage : | 32GB/64GB eMMC 5.1 onboard, SATA 6Gb/s x 2 |
| USB Ports: | USB 2.0 x8, USB3.2 GEN2 x 2 (Rear) |
| Expansion : | PCIe x1 Gen3 x 4 |
| Power Requirement: | AT: +12V, ATX: +12V, +5VSB, Wide range input: +4.75V to +20V |
| TPM : | TPM 2.0 |
| Operating Temperature: | -20 to +70 degC / -40 to +85 degC |
| Ethernet Technical Data: | 1 x I²C, 1 x LPC, 1 x SPI, 2 x TX/RX , 4-CH in/out GPIO, 10/100/1000/2500 Mbps Ethernet with Intel® I226 x 1, Smart Battery support |
