CAPA55R
Key features:
- 11th gen Intel® Core™ i7/i5/i3 & Celeron® Processor
- 2 DDR4 SO-DIMM for up to 64GB of memory GbE LAN and 2.5
- GbE LAN ports
- 3 M.2 expansion slot
| Model | CAPA55RPHGG-i7-1185G7E w/fan | CAPA55RPHGG-i5-1145G7E w/fan | CAPA55RPHGG-i3-1115G4E w/fan | CAPA55RPHGGCELERON-6305E w/fan | CAPA55R-I71185-H | CAPA55R-I51145-H | CAPA55R-I31115-H | CAPA55R-6305E-H |
| Processor | 11th gen Intel® Core™ i7-1185G7E | 11th gen Intel® Core™ i5-1145G7E | 11th gen Intel® Core™ i3-1115G4E | 11th gen Intel® Celeron® 6305E | 11th gen Intel® Core™ i7-1185G7E | 11th gen Intel® Core™ i5-1145G7E | 11th gen Intel® Core™ i3-1115G4E | 11th gen Intel® Celeron® 6305E |
| Display | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS |
| LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN |
| Other | cooler | cooler | cooler | cooler | heatsink | heatsink | heatsink | heatsink |
If you are interested in our product, you can contact us through our contact page.
In order to use the wishlist please make sure you are registered as a user to proceed.
OK
SKU:
CAPA55R
Product information "CAPA55R"
Key features:
- 11th gen Intel® Core™ i7/i5/i3 & Celeron® Processor
- 2 DDR4 SO-DIMM for up to 64GB of memory GbE LAN and 2.5
- GbE LAN ports
- 3 M.2 expansion slot
| Model | CAPA55RPHGG-i7-1185G7E w/fan | CAPA55RPHGG-i5-1145G7E w/fan | CAPA55RPHGG-i3-1115G4E w/fan | CAPA55RPHGGCELERON-6305E w/fan | CAPA55R-I71185-H | CAPA55R-I51145-H | CAPA55R-I31115-H | CAPA55R-6305E-H |
| Processor | 11th gen Intel® Core™ i7-1185G7E | 11th gen Intel® Core™ i5-1145G7E | 11th gen Intel® Core™ i3-1115G4E | 11th gen Intel® Celeron® 6305E | 11th gen Intel® Core™ i7-1185G7E | 11th gen Intel® Core™ i5-1145G7E | 11th gen Intel® Core™ i3-1115G4E | 11th gen Intel® Celeron® 6305E |
| Display | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS | DisplayPort++, HDMI, LVDS |
| LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN | GbE LAN, 2.5GbE LAN |
| Other | cooler | cooler | cooler | cooler | heatsink | heatsink | heatsink | heatsink |
| CPU: | 6305E, i3-1115G4E, i5-1145G7E, i7-1185G7E |
|---|---|
| Processor Family: | Intel® Celeron®, Intel® Core |
| Memory : | 64GB |
| Display : | Display Port, HDMI, LVDS, eDP |
| Storage : | SATA III x1 |
| USB Ports: | USB2.0 x 4 (header), USB3.2 Gen2 x3 |
| Expansion : | M.2 2230 E-Key x 1, M.2 3042 B-Key x1, SIM |
| Power Requirement: | 12V to 24V |
| Operating Temperature : | 0 to +60 degC |
| Ethernet Technical Data: | 1GbE RJ-45 x 1, 2.5GbE RJ-45 x 1, i219-LM x1, i226 |
